Goods elevator with a lift tower for 1000 kg

inc. vat 78.606,05 EUR ex. vat 62.884,84 EUR
Prisen på dette produkt er et priseksempel. Kontakt os for en pris på jeres projekt.

Betal via
faktura

Over 40 års
erfaring

Speciallavede
løsninger

Goods lift with a lifting capacity of 1000 kg to transport goods between two floors.

The goods lift from JEMA LIFT is produced at our factory in Denmark. We produce the lift ourselves, so we are also flexible and can produce in other sizes and capabilities if desired. Of course, we are also prepared to offer an offer on a product elevator that must be adapted to existing conditions where the standard solution cannot be used.

Technical specifications:

Scissor type
LT-1818LH60T1
Lifting time 0.05 m / sec
Capacity - evenly distributed load 1000 kg
Length 1800 mm
Width 1800 mm
Lift stroke
6900 mm
Min. height
8 mm
Control Operator permitted along with goods
Passenger transport No
Use 2 pcs. Pulse push-button controlled


Also made on special dimensions - Contact us


Technical description:

Profile steel arms in high strength steel gives the lifting table a very large side stability. Long bushings with grease nipples in all moving joints reduce the load in the most exposed places and ensure a long life with minimal maintenance. Rolls and wheels are forkeletter, providing a very long life and very low maintenance costs.

Basis of CE marking:

The product elevator meets all applicable circulars and regulations. It is supplied tested and CE marked according to the machine directive and standard DS EN 1570 incl. Documentation and test certificate

Guarantee:

A 1 year warranty from Jema Lift is granted on errors and defects due to the lift's construction and setup. The warranty period requires Max. 8 hours of use / days. Or Max 80 lift per day.

Pit:

This solution requires a pit. Grubs can be handed over by offer or order.

Inspection:

The product elevator must have a minimum of 2 annual statutory inspection. We offer a fixed price for the first inspection, and we will then carry out inspection to a price calculated from our first visit.


Delivery and assembly of product elevator:

The price is incl. Delivery and assembly.

In order for the mounting site to be reported, the following conditions must be clarified or performed:

  • Load tubes for wires and hydraulic hose must be established to the pit.
  • Placing pump station and control must be designated.
  • Grube dimensions must be complied with
  • Grube must be emptied of any waste, building materials and water.
  • Cottage around pit must be completed.
  • Power with switch must be led to location for the control.
  • Possibility to pull wires for operations and door locks must be present.
  • Any aids in connection with placement of lifting table in pit must be present.
  • If there is a need for crane, truck or other aids to mount the product elevator, this will be settled separately.
